Mimaki TS100-1600 Sublimation Printer
Hover over image to zoom
)
Product Description
Mimaki TS100-1600 Sublimation Printer
- Pricing DOES NOT INCLUDE: Taxes (if applicable), ink, setup, installation, training and freight.
- Call us for an ALL IN Price Quotation!
- Includes (12) months of TOTAL CARE Warranty Coverage
Benefits & Features:
Entry-Level Price, Professional Results
The TS100-1600 is an affordable professional grade sublimation roll-based printer. Consistently and expertly print highly detailed photographic quality graphics for small to large production runs
Features:
- Available in 64” with print speeds up to 753 Sq Ft/Hr
- Nozzle Check Unit (NCU), automatically monitors printhead performance and detects clogged nozzles
- Nozzle Recovery System (NRS), automatically substitutes unproductive nozzles, avoiding unnecessary downtime and poor image quality
- Sublimation ink colors: Blue, Magenta, Yellow and Black
- NEW Dot Adjustment System (DAS) automatically aligns to ensure consistent quality and repeatability
- NEW, easier to use RIP software, RasterLink7, included; reduces RIP time by 25%
- TxLink4 Lite supported for more advanced workflows
Core Technologies:
- Mimaki Circulation Technology
- Waveform Control
- Variable Dot Technology
- Mimaki Advanced Pass System
- Nozzle Check Unit
- Nozzle Recovery System
- Mimaki Bulk Ink
- Uninterrupted Ink Supply
- Mimaki Fine Diffusion
Specifications:
- Printhead: Four in-line on-demand piezo heads
- Print Resolutions: 360 dpi, 540 dpi, 720 dpi, 1,080 dpi
- Print Speed (4-color Mode): up to 1237.85 SqFt/Hr (115 m2/h)
- Maximum Print Area: 76.4″ (1940 mm)
- Maximum Media Width: 76.8″ (1950 mm)
- Maximum Media Thickness: up to 0.04″ (1 mm)
- Maximum Media Weight: 88.2 lbs. (40.0 kg)
- Ink Type: U.S. & Canada- Sb410, Sb411
- Interface: Ethernet 1000BASE-T, USB2.0 Hi-speed
- Power Supply: Single-phase (AC100 – 120V / AC200 – 240V)
- Power Consumption: AC100V: 1.44kW or less | AC200V: 1.92kW or less
- Operational Enviroment: Temperature 68° – 86° F (20-30° C)
Humidity: 35–65 % RH (Non condensing) - Dimensions (W x D x H): 126″ x 33.4″ x 73.1″ (320 x 84.8 x 185.7 cm)
- Weight: 469.6 lbs. (213 kg)
- Certifications: VCCI class A, FCC class A, ETL UL 60950-1, CE Marking (EMC, Low voltage, Machinery directive, and RoHS), CB, REACH, Energy Star, RCM
Applications:
- Soft
- Wallpaper
- Curtains
- Signage
- Exhibitions
- Jersey's
- Sails / Flags
