Vanguard VK3220-HS | 80" X 120" Flatbed UV Printer w/Kyocera print heads

The VK3220-HS redefines the meaning of productivity on a 3.2 x 2 meter (126” x 80”) UV-LED flatbed. With up to three rows of printheads, print speeds can reach over 3,800 square feet per hour. Utilizing 4 picoliter drop size Kyocera heads and a high-speed magnetic drive, there’s no compromise on speed to achieve remarkable quality. With the ability to print up to 10cm thick, the only limitation is your imagination.

Your goal is to grow your business. Vanguard's goal for your business is the same! That’s why they created the Growing Your Business Together Program.  Field Upgradable printers that can grow with additional print heads to meet the demands of your business needs! You can choose from 2 print heads to 10!

REDEFINED PRODUCTIVITY WITH REMARKABLE PRINT QUALITY:

• CMYK + optional White + Varnish for expanded application potential.

• Larger bed size for greater throughput potential.

• Up to three rows of printheads to best suit business needs with the option to upgrade speed and channels as needs change and develop in the future.

• Variable drop technology and 4 picoliter drop sizes for better color gradients and smoothing capability.

• Precise dot placement for sharper lines and text at high print speeds.

• Magnetic linear drive control for accurate dot placement at ultra-high speeds.

• High-volume ink jetting at an accurate level to support productivity.

• Solid aluminum table with flatness of +/- 50 microns.

• Seven-zone, user-selectable vacuum system ensures efficient hold-down, no unintended media movement, and easy transitions between jobs.

THE POWER OF LED TECHNOLOGY:

• Extends your range of supported substrates, including lower-cost and added-value specialty media.

• Increases uptime and productivity with instant on/off and less maintenance.

• Drive down operating costs with less energy consumption and fewer consumable parts.

• Reduces waste with consistent color output and simple operation.

• Satisfies customer requests for a greener print solution with no VOCs, lower power consumption, and less waste and consumables.

Need to increase production? Add print heads!
single row of heads = up to 30 boards per hour
dual row of heads = up to 60 boards per hour

Need more colors? Add ink!
white and clear ink channels are optional
