VKH900-HS | 98" Hybrid UV Printer w/Kyocera print heads

The versatile VKH900-HS Hybrid UV-LED combines our award winning VK300D-HS flatbed printer with the capabilities of our VKR3200-HS roll to roll printer. Maximizing the key features of each platform, we achieved astonishing speed and clarity, utilizing Kyocera’s KJ4A printhead, on either flat materials or roll stock.

The VKH900-HS is a field expandable platform allowing up to 15 Kyocera KJ4A print heads, in a 3 row configuration (3 each CMYKW). With a versatile print zone of 2.5 m (98”), the VKH900-HS is designed to accommodate industry standard rolls up to 98” wide and flat media up to 2.5” thick and 10 lbs/sqft. As with all Vanguard printers, this hybrid continues to utilize fully adjustable liquid-cooled UV-LED lamps which will allow for printing on heat sensitive materials faster than competitive technologies.

Your goal is to grow your business. Vanguard's goal for your business is the same! That’s why they created the Growing Your Business Together Program.  Field Upgradable printers that can grow with additional print heads to meet the demands of your business needs! You can choose from 2 print heads to 10!

Need to increase production? Add print heads!
single row of heads = up to 30 boards per hour
dual row of heads = up to 60 boards per hour

Need more colors? Add ink!
white and clear ink channels are optional
