Vanguard VK300D-HS | 5 X 10 Flatbed UV Printer w/Kyocera print heads

Built on the 6-time award winning VK300D series, the 5’ x 10’ VK300D-HS UV-LED true flatbed is the best 5’ x 10’ digital flatbed printer, period! This fully featured printer revolutionizes the industry with a high-speed electromagnetic drive system that propels the carriage at speeds up to 1.8m per second for an incredible 60 boards per hour. This impressive advancement ensures your business will out produce any competitor. The VK300D-HS comes equipped with industrial Kyocera KJ4A printheads that deliver print dots as small as 4pl ensuring tight dot placement for vivid output on virtually any substrate up to 4” thick. Other features include auto height detection, one-touch pin registration, front-to-back and back-to-front printing, water-cooled LED curing technology, ionization bars, 6 reversible vacuum zones and supports CMYK, W & V. The VK300D-HS is engineered to grow with your business and is field expandable up to 10 printheads via 2 rows of printheads.  61.3"x125.5" max print area.

Your goal is to grow your business. Vanguard's goal for your business is the same! That’s why they created the Growing Your Business Together Program.  Field Upgradable printers that can grow with additional print heads to meet the demands of your business needs! You can choose from 2 print heads to 10!

REMARKABLE PRODUCTIVITY & IMAGE QUALITY:

• CMYK + White + Varnish with single-pass, multi-layer printing for expanded application potential.

• 3 Level Greyscale with variable drop technology and 4 picoliter drop sizes for better color gradients and smoothing capability.

• Equipped with automatic height detection for faster job setup and one-touch pin registration for easy front-to-back and back-to-front printing.

• Durst Workflow prepress & RIP software solution with Vanguard interactive G.U.I.

PRECISE AND ACCURATE DOT PLACEMENT FROM PRINT TO PRINT:

• Magnetic linear drive control for precise drop placement for sharper lines and text.

• High-volume ink jetting at an accurate level to support productivity.

• Solid aluminum table with flatness of +/- 50 microns.

• Six-zone, user-selectable reversible vacuum system ensures efficient hold-down, no unintended media movement, and easy transitions between jobs

THE POWER OF LED TECHNOLOGY:

• Extends your range of supported substrates, including lower-cost and added-value specialty media.

• Increases uptime and productivity with instant on/off and less maintenance.

• Drive down operating costs with less energy consumption and fewer consumable parts.

• Reduces waste with consistent color output and simple operation.

• Satisfies customer requests for a greener print solution with low VOCs, lower power consumption, and less waste and consumables.

Need to increase production? Add print heads!
single row of heads = up to 30 boards per hour
dual row of heads = up to 60 boards per hour

Need more colors? Add ink!
white and clear ink channels are optional
